TTC-5017
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy TTC-5017 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy TTC-5017 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | TTC-5017 |
|---|---|
| Manufacturer | Tamura |
| Description | TRANSFORMER TELECOMM 600:600 OHM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $1.82 | $1.382 | $1.346 | $1.236 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $1.164 | $1.127 | $1.091 | $1.055 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | TTC-5017 | Manufacturer | Tamura |
|---|---|---|---|
| Description | TRANSFORMER TELECOMM 600:600 OHM | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 37065 pcs | Data sheet | TTC-5017 |
| Category | Transformers | Weight | - |
| Voltage - Isolation | 1875VRMS @ 1 Second | Turns Ratio - Primary:Secondary | 1:1 |
| Transformer Type | Data/Voice Coupling | Termination Style | PC Pin |
| Size / Dimension | 0.591" L x 0.571" W (15.00mm x 14.50mm) | Series | TTC |
| Return Loss | 14dB Min @ 200Hz ~ 4kHz | Power Level | - |
| Packaging | Bulk | Other Names | MT7207 TTC-5017F TTC5017 |
| Operating Temperature | - | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 26 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insertion Loss | 1.5dB Max @ 1kHz |
| Impedance - Secondary (Ohms) | 600 | Impedance - Primary (Ohms) | 600 |
| Height - Seated (Max) | 0.472" (12.00mm) | Frequency Response | ±0.5dB |
| Frequency Range | 200Hz ~ 4kHz | DC Resistance (DCR) - Secondary | 59 Ohm |
| DC Resistance (DCR) - Primary | 59 Ohm | Approvals | UL60950 |
