TTC-10
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy TTC-10 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy TTC-10 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | TTC-10 |
|---|---|
| Manufacturer | Tamura |
| Description | TRANSF TELE COUP 600 OHM 0 MADC |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | TTC-10 | Manufacturer | Tamura |
|---|---|---|---|
| Description | TRANSF TELE COUP 600 OHM 0 MADC | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 5635 pcs | Data sheet | TTC-10 |
| Category | Transformers | Weight | - |
| Voltage - Isolation | 1500VRMS @ 1 Minute | Turns Ratio - Primary:Secondary | 1:0.736 |
| Transformer Type | Data/Voice Coupling | Termination Style | PC Pin |
| Size / Dimension | 0.799" L x 0.689" W (20.30mm x 17.50mm) | Series | TTC |
| Return Loss | - | Power Level | 7dB |
| Packaging | Bulk | Other Names | MT4115 T2220 T2220(BOX) T2220(BULK) |
| Operating Temperature | - | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insertion Loss | 1.2dB Max @ 1kHz | Impedance - Secondary (Ohms) | 600/600 |
| Impedance - Primary (Ohms) | 600 | Height - Seated (Max) | 0.752" (19.10mm) |
| Frequency Response | ±0.5dB | Frequency Range | 300Hz ~ 3.5kHz |
| DC Resistance (DCR) - Secondary | 42 Ohm | DC Resistance (DCR) - Primary | 57 Ohm |
| Approvals | CSA-C22.2 No. 66-M1988, UL1459 |
