Home > Products > Transformers > Power Transformers > VPT30-3330

VPT30-3330

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy VPT30-3330 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	VPT30-3330
Manufacturer	Triad Magnetics
Description	XFRMR TOROIDAL 100VA CHAS MOUNT
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 3525 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	25 pcs	50 pcs	100 pcs
Reference Price (In US Dollars)	$14.059	$12.407	$11.993	$10.752	$10.339

Product parameter
Data sheet

Product parameter

Part Number	VPT30-3330	Manufacturer	Triad Magnetics
Description	XFRMR TOROIDAL 100VA CHAS MOUNT	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	3525 pcs	Data sheet	VPT30-3330
Category	Transformers	Weight	2.2 lbs (997.9g)
Voltage - Secondary (Full Load)	Parallel 15V, Series 30V	Voltage - Primary	115V, 230V
Voltage - Isolation	4000Vrms	Type	Toroidal
Termination Style	Wire Leads	Size / Dimension	87.00mm Dia x 47.00mm W
Series	Chassis Mount: World Series™	Secondary Winding(s)	Dual
Primary Winding(s)	Dual	Power - Max	100 VA
Other Names	237-1340 VPT303330	Mounting Type	Chassis Mount
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Manufacturer Standard Lead Time	12 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Height - Seated (Max)	-
Current - Output (Max)	Parallel 6.66A, Series 3.33A	Center Tap	No

This browser does not support inline PDFs. Please download the PDF to view it: Download PDF
