TTC-167
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy TTC-167 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy TTC-167 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | TTC-167 |
|---|---|
| Manufacturer | Tamura |
| Description | TRANSF TELE COUP 10K:10K 0MADC |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $2.468 | $1.875 | $1.825 | $1.677 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $1.579 | $1.529 | $1.48 | $1.431 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | TTC-167 | Manufacturer | Tamura |
|---|---|---|---|
| Description | TRANSF TELE COUP 10K:10K 0MADC | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 26363 pcs | Data sheet | TTC-167 |
| Category | Transformers | Weight | - |
| Voltage - Isolation | 1000VRMS @ 1 Minute | Turns Ratio - Primary:Secondary | 1:1 |
| Transformer Type | Data/Voice Coupling | Termination Style | PC Pin |
| Size / Dimension | 0.610" L x 0.689" W (15.50mm x 17.50mm) | Series | TTC |
| Return Loss | - | Power Level | - |
| Packaging | Bulk | Other Names | MT11107 MT4139 TTC167 |
| Operating Temperature | - | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 26 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insertion Loss | 1.7dB Max @ 1kHz |
| Impedance - Secondary (Ohms) | 10k | Impedance - Primary (Ohms) | 10k |
| Height - Seated (Max) | 0.551" (14.00mm) | Frequency Response | ±1dB |
| Frequency Range | 300Hz ~ 4kHz | DC Resistance (DCR) - Secondary | 420 Ohm |
| DC Resistance (DCR) - Primary | 330 Ohm | Approvals | CSA-C22.2 No. 66-M1988, UL1863 |
