DS1-30-0003
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy DS1-30-0003 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy DS1-30-0003 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | DS1-30-0003 |
|---|---|
| Manufacturer | Schurter |
| Description | COMMON MODE CHOKE 3.15A 2LN TH |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 50 pcs | 100 pcs | 500 pcs | 1000 pcs |
|---|---|---|---|---|---|
| $3.39 | $2.868 | $2.451 | $2.138 | $1.929 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | DS1-30-0003 | Manufacturer | Schurter |
|---|---|---|---|
| Description | COMMON MODE CHOKE 3.15A 2LN TH | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 17283 pcs | Data sheet | DS |
| Category | Filters | Voltage Rating - DC | 600V |
| Voltage Rating - AC | - | Size / Dimension | 1.181" L x 1.181" W (30.00mm x 30.00mm) |
| Series | DS | Ratings | - |
| Packaging | Bulk | Package / Case | Radial - 4 Leads |
| Other Names | 486-3098 DS1-30-0003-ND DS1-30-3.15-150/A |
Operating Temperature | -40°C ~ 125°C |
| Number of Lines | 2 | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | Not Applicable | Manufacturer Standard Lead Time | 12 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Height (Max) | 0.591" (15.00mm) |
| Filter Type | - | Features | - |
| Detailed Description | 2 Line Common Mode Choke Through Hole 3.15A DCR 55 mOhm | DC Resistance (DCR) (Max) | 55 mOhm |
| Current Rating (Max) | 3.15A | Approvals | - |
This browser does not support inline PDFs. Please download the PDF to view it: Download PDF
