DS1-25-0003
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy DS1-25-0003 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy DS1-25-0003 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | DS1-25-0003 |
|---|---|
| Manufacturer | Schurter |
| Description | COMMON MODE CHOKE 3.15A 2LN TH |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 50 pcs | 100 pcs | 500 pcs | 1000 pcs |
|---|---|---|---|---|---|
| $2.755 | $2.331 | $1.992 | $1.737 | $1.568 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | DS1-25-0003 | Manufacturer | Schurter |
|---|---|---|---|
| Description | COMMON MODE CHOKE 3.15A 2LN TH | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 22364 pcs | Data sheet | DS |
| Category | Filters | Voltage Rating - DC | 600V |
| Voltage Rating - AC | - | Size / Dimension | 0.984" L x 0.984" W (25.00mm x 25.00mm) |
| Series | DS | Ratings | - |
| Packaging | Bulk | Package / Case | Radial |
| Other Names | 486-3145 DS1-25-0003-ND DS1-25-3.15-100/A |
Operating Temperature | -40°C ~ 125°C |
| Number of Lines | 2 | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 23 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Filter Type | - |
| Features | - | Detailed Description | 2 Line Common Mode Choke Through Hole 3.15A DCR 40 mOhm |
| DC Resistance (DCR) (Max) | 40 mOhm | Current Rating (Max) | 3.15A |
| Approvals | - |
