AH284-PG-B


OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy AH284-PG-B with confidence from Components-World.HK, 1 Year Warranty
Dowload AH284-PG-B Details in PDFSee Product Specifications for product details.
Buy AH284-PG-B with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
Part Number | AH284-PG-B |
---|---|
Manufacturer | Diodes Incorporated |
Description | IC MOTOR DRIVER ON/OFF SIP4L |
Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
Reference Price (In US Dollars) | Get a quote |
- Product parameter
- Data sheet
Product parameter
Part Number | AH284-PG-B | Manufacturer | Diodes Incorporated |
---|---|---|---|
Description | IC MOTOR DRIVER ON/OFF SIP4L | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
Quantity Available | 5949 pcs | Data sheet | AH284 |
Category | Integrated Circuits (ICs) | Voltage - Supply | 3.8 V ~ 20 V |
Voltage - Load | 3.8 V ~ 20 V | Technology | Power MOSFET |
Supplier Device Package | 4-SIP | Step Resolution | - |
Series | - | Packaging | Bulk |
Package / Case | 4-SSIP | Output Configuration | Low Side (2) |
Other Names | AH284-PG-BDI | Operating Temperature | -40°C ~ 150°C (TJ) |
Mounting Type | Through Hole | Motor Type - Stepper | - |
Motor Type - AC, DC | Brushless DC (BLDC) | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Interface | On/Off |
Function | Driver - Fully Integrated, Control and Power Stage | Detailed Description | Motor Driver Power MOSFET On/Off 4-SIP |
Current - Output | 500mA | Base Part Number | AH284 |
Applications | Fan Motor Driver |
