Home > Products > Switches > Rocker Switches > GW12LJPD

GW12LJPD

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy GW12LJPD with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	GW12LJPD
Manufacturer	NKK Switches
Description	SWITCH ROCKER SPDT 0.4VA 28V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	100 pcs	300 pcs	500 pcs	1000 pcs
~~In Stock~~ 23561 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	25 pcs	50 pcs
	$1.886	$1.795	$1.705	$1.616
	$1.593	$1.548	$1.481	$1.301

Product parameter
Data sheet

Product parameter

Part Number	GW12LJPD	Manufacturer	NKK Switches
Description	SWITCH ROCKER SPDT 0.4VA 28V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	23561 pcs	Data sheet	GW Series Datasheet
Category	Switches	Voltage Rating - DC	28V
Voltage Rating - AC	28V	Termination Style	PC Pin
Switch Function	On-On	Series	GW
Panel Cutout Dimensions	-	Packaging	Tray
Other Names	360-2110 GW12LJPD-RO	Operating Temperature	-25°C ~ 55°C
Mounting Type	Through Hole	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Mechanical Life	50,000 Cycles	Manufacturer Standard Lead Time	5 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Ingress Protection	-
Illumination Voltage (Nominal)	2 VDC	Illumination Type, Color	LED, Amber
Features	Sealed - Flux Protection	Electrical Life	50,000 Cycles
Detailed Description	Rocker Switch SPDT 0.4VA (AC/DC) 28V Through Hole	Current Rating	0.4VA (AC/DC)
Color - Actuator/Cap	Clear	Circuit	SPDT
Actuator Type	Paddle - Illuminated	Actuator Marking	No Marking
