NCP45521IMNTWG-L
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy NCP45521IMNTWG-L with confidence from Components-World.HK, 1 Year Warranty
Dowload NCP45521IMNTWG-L Details in PDFSee Product Specifications for product details.
Buy NCP45521IMNTWG-L with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | NCP45521IMNTWG-L |
|---|---|
| Manufacturer | ON Semiconductor |
| Description | IC LOAD SWITCH ACT-LO 10.5A 8DFN |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 3000 pcs | 6000 pcs | 15000 pcs | ||
|---|---|---|---|---|---|
| $0.156 | $0.149 | $0.143 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | NCP45521IMNTWG-L | Manufacturer | ON Semiconductor |
|---|---|---|---|
| Description | IC LOAD SWITCH ACT-LO 10.5A 8DFN | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 167536 pcs | Data sheet | NCP45520,21 |
| Category | Integrated Circuits (ICs) | Voltage - Load | 12.8 mOhm |
| Voltage - Breakdown | 8-DFN (2x2) | Series | ecoSWITCH™ |
| RoHS Status | Tape & Reel (TR) | Polarization | 8-VFDFN Exposed Pad |
| Output Type | N-Channel | Output Configuration | 1 |
| Other Names | NCP45521IMNTWG-L-ND NCP45521IMNTWG-LOSTR |
Operating Temperature | -40°C ~ 85°C (TA) |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | Manufacturer Standard Lead Time | 18 Weeks |
| Manufacturer Part Number | NCP45521IMNTWG-L | Interface | On/Off |
| Input Type | Non-Inverting | Features | Slew Rate Controlled |
| Feature Pins | 10.5A | Driven Configuration | 0.5 V ~ 13.5 V |
| Differential - Input:Output | 1:1 | Description | IC LOAD SWITCH ACT-LO 10.5A 8DFN |
| Data Converters | 3 V ~ 5.5 V | Control Features | Over Temperature, UVLO |
| Contact Rating @ Voltage | High Side | Auxiliary Sense | General Purpose |
