30126
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 30126 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 30126 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 30126 |
|---|---|
| Manufacturer | dresden elektronik |
| Description | RF TXRX MODULE 802.15.4 U.FL ANT |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | 30126 | Manufacturer | dresden elektronik |
|---|---|---|---|
| Description | RF TXRX MODULE 802.15.4 U.FL ANT | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 4397 pcs | Data sheet | 30125, 30126 BriefRadio Modules User ManualRadio Modules USB Sticks Guide28498, 28987 Datasheet |
| Category | RF/IF and RFID | Voltage - Supply | 1.8 V ~ 3.6 V |
| Utilized IC / Part | CC1101 | Series | deRFmega128 |
| Serial Interfaces | I²C, JTAG, SPI, UART | Sensitivity | -101dBm |
| RF Family/Standard | 802.15.4 | Protocol | 6LoWPAN, Zigbee® |
| Power - Output | 2.4dBm | Packaging | Bulk |
| Package / Case | Module | Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Modulation | - | Memory Size | - |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Frequency | 2.4GHz |
| Data Rate | 2Mbps | Current - Transmitting | 18mA |
| Current - Receiving | 18mA | Antenna Type | Not Included, U.FL |
This browser does not support inline PDFs. Please download the PDF to view it: Download PDF
