Home > Products > Filters > Common Mode Chokes > 7427521

7427521

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 7427521 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	7427521
Manufacturer	Wurth Electronics
Description	CMC 5A 2LN 52 OHM SMD
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 51576 pcs
Reference Price (In US Dollars)	2400 pcs
Reference Price (In US Dollars)	$0.635

Product parameter
Data sheet

Product parameter

Part Number	7427521	Manufacturer	Wurth Electronics
Description	CMC 5A 2LN 52 OHM SMD	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	51576 pcs	Data sheet	7427521
Category	Filters	Voltage Rating - DC	-
Voltage Rating - AC	-	Size / Dimension	0.335" L x 0.220" W (8.50mm x 5.60mm)
Series	WE-CMS	Ratings	-
Packaging	Tape & Reel (TR)	Package / Case	0302 (0805 Metric)
Other Names	732-2358-2 7427521-ND Q4948396 Q5161352 T1044318	Operating Temperature	-40°C ~ 125°C
Number of Lines	2	Mounting Type	Surface Mount
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Manufacturer Standard Lead Time	11 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Impedance @ Frequency	52 Ohms @ 100MHz
Height (Max)	0.126" (3.20mm)	Filter Type	Power, Signal Line
Features	-	Detailed Description	2 Line Common Mode Choke Surface Mount 52 Ohms @ 100MHz 5A DCR 3 mOhm
DC Resistance (DCR) (Max)	3 mOhm	Current Rating (Max)	5A
Approvals	-

This browser does not support inline PDFs. Please download the PDF to view it: Download PDF
