690367181072
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 690367181072 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 690367181072 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
Part Number | 690367181072 |
---|---|
Manufacturer | Wurth Electronics |
Description | CONN 2.54MM FEMALE STR RED 10POS |
Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
Reference Price (In US Dollars) | 1 pcs | 10 pcs | 100 pcs | 250 pcs | 500 pcs |
---|---|---|---|---|---|
$0.325 | $0.32 | $0.307 | $0.295 | $0.264 |
- Product parameter
- Data sheet
Product parameter
Part Number | 690367181072 | Manufacturer | Wurth Electronics |
---|---|---|---|
Description | CONN 2.54MM FEMALE STR RED 10POS | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
Quantity Available | 87286 pcs | Data sheet | 69036718xx7x DrawingMiniModule Conn WR-MM |
Category | Connectors, Interconnects | Voltage Rating | 100VAC |
Termination | Kinked Pin, Solder | Style | Board to Board or Cable |
Series | WR-MM | Row Spacing - Mating | 0.059" (1.50mm) |
Pitch - Mating | 0.100" (2.54mm) | Packaging | Tube |
Other Names | 732-1973-5 | Operating Temperature | -40°C ~ 105°C |
Number of Rows | 2 | Number of Positions Loaded | All |
Number of Positions | 10 | Mounting Type | Through Hole |
Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-0 |
Mated Stacking Heights | - | Manufacturer Standard Lead Time | 17 Weeks |
Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insulation Material | Polybutylene Terephthalate (PBT) |
Insulation Height | 0.157" (4.00mm) | Insulation Color | Red |
Ingress Protection | - | Features | - |
Fastening Type | Push-Pull | Detailed Description | 10 Position Receptacle Connector 0.100" (2.54mm) Through Hole Tin |
Current Rating | 1.5A per Contact | Contact Type | Forked |
Contact Shape | Rectangular | Contact Material | Phosphor Bronze |
Contact Length - Post | 0.122" (3.10mm) | Contact Finish Thickness - Post | - |
Contact Finish Thickness - Mating | - | Contact Finish - Post | Tin |
Contact Finish - Mating | Tin | Connector Type | Receptacle |
Applications | - |
This browser does not support inline PDFs. Please download the PDF to view it: Download PDF
