Home > Products > Relays > Power Relays, Over 2 Amps > 8690130000

8690130000

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 8690130000 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	8690130000
Manufacturer	Weidmuller
Description	RELAY GEN PURPOSE 4PDT 6A 48V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 3946 pcs
Reference Price (In US Dollars)	10 pcs
Reference Price (In US Dollars)	$8.465

Product parameter
Data sheet

Product parameter

Part Number	8690130000	Manufacturer	Weidmuller
Description	RELAY GEN PURPOSE 4PDT 6A 48V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	3946 pcs	Data sheet	8690130000
Category	Relays	Turn On Voltage (Max)	38.4 VAC
Turn Off Voltage (Min)	14.4 VAC	Termination Style	Plug In, Quick Connect - 0.110" (2.8mm)
Switching Voltage	240VAC - Max	Series	RCM
Release Time	10ms	Relay Type	General Purpose
Packaging	Bulk	Operating Temperature	-40°C ~ 70°C
Operate Time	15ms	Mounting Type	Socketable
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Manufacturer Standard Lead Time	8 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Features	LED Indicator, Test Button
Detailed Description	General Purpose Relay 4PDT (4 Form C) 48VAC Coil Socketable	Contact Rating (Current)	6A
Contact Material	Silver Nickel (AgNi)	Contact Form	4PDT (4 Form C)
Coil Voltage	48VAC	Coil Type	Non Latching
Coil Resistance	777 Ohms	Coil Power	1 VA
Coil Current	21.3mA
