F4-10
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy F4-10 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy F4-10 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | F4-10 |
|---|---|
| Manufacturer | Triad Magnetics |
| Description | XFRMR LAMINATED THRU HOLE |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $3.24 | $2.52 | $2.452 | $2.111 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $2.016 | $1.975 | $1.941 | $1.907 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | F4-10 | Manufacturer | Triad Magnetics |
|---|---|---|---|
| Description | XFRMR LAMINATED THRU HOLE | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 16957 pcs | Data sheet | F4-10 DataSheet |
| Category | Transformers | Weight | 0.44 lb (199.58g) |
| Voltage - Secondary (Full Load) | 10V | Voltage - Primary | 115V |
| Voltage - Isolation | 2500VAC | Type | Laminated Core |
| Termination Style | Solder, Quick Connect - 0.187" (4.7mm) | Size / Dimension | 60.33mm L x 31.75mm W |
| Series | Quick Pack | Secondary Winding(s) | Single |
| Primary Winding(s) | Single | Power - Max | 6 VA |
| Other Names | 237-1679 | Mounting Type | Chassis Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 16 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Height - Seated (Max) | 34.93mm |
| Current - Output (Max) | 600mA | Center Tap | Yes |
This browser does not support inline PDFs. Please download the PDF to view it: Download PDF
