F-96U
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy F-96U with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy F-96U with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | F-96U |
|---|---|
| Manufacturer | Triad Magnetics |
| Description | POWER XFMR CHASSIS MOUNT W/LEADS |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $7.72 | $6.813 | $6.586 | $5.904 | $5.677 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | F-96U | Manufacturer | Triad Magnetics |
|---|---|---|---|
| Description | POWER XFMR CHASSIS MOUNT W/LEADS | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 5909 pcs | Data sheet | F-96U Datasheet |
| Category | Transformers | Weight | 2.1 lbs (952.5g) |
| Voltage - Secondary (Full Load) | 10V | Voltage - Primary | 115V |
| Voltage - Isolation | 1500Vrms | Type | Laminated Core |
| Termination Style | Wire Leads | Size / Dimension | 63.50mm L x 69.85mm W |
| Series | Single Secondary | Secondary Winding(s) | Single |
| Primary Winding(s) | Single | Power - Max | 60 VA |
| Other Names | 237-2012 | Mounting Type | Chassis Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 16 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Height - Seated (Max) | 76.20mm |
| Current - Output (Max) | 6A | Center Tap | Yes |
This browser does not support inline PDFs. Please download the PDF to view it: Download PDF
