F-254X
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy F-254X with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy F-254X with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | F-254X |
|---|---|
| Manufacturer | Triad Magnetics |
| Description | CHASSIS MOUNT POWER TRANSFORMER |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | ||||
|---|---|---|---|---|---|
| $6.103 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | F-254X | Manufacturer | Triad Magnetics |
|---|---|---|---|
| Description | CHASSIS MOUNT POWER TRANSFORMER | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 5453 pcs | Data sheet | F-254X Datasheet |
| Category | Transformers | Weight | 1.5 lbs (680.4g) |
| Voltage - Secondary (Full Load) | 20V | Voltage - Primary | 115V |
| Voltage - Isolation | 1500Vrms | Type | Laminated Core |
| Termination Style | Wire Leads | Size / Dimension | 93.65mm L x 49.20mm W |
| Series | - | Secondary Winding(s) | Single |
| Primary Winding(s) | Single | Power - Max | 20 VA |
| Mounting Type | Chassis Mount | Moisture Sensitivity Level (MSL) | Not Applicable |
| Manufacturer Standard Lead Time | 16 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Height - Seated (Max) | 57.15mm | Current - Output (Max) | 1A |
| Center Tap | Yes |
This browser does not support inline PDFs. Please download the PDF to view it: Download PDF
