F-237Z
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy F-237Z with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy F-237Z with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | F-237Z |
|---|---|
| Manufacturer | Triad Magnetics |
| Description | CHASSIS MOUNT POWER TRANSFORMER |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | ||||
|---|---|---|---|---|---|
| $6.124 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | F-237Z | Manufacturer | Triad Magnetics |
|---|---|---|---|
| Description | CHASSIS MOUNT POWER TRANSFORMER | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 5056 pcs | Data sheet | F-237Z Datasheet |
| Category | Transformers | Weight | 1.1 lbs (499g) |
| Voltage - Secondary (Full Load) | Parallel 12V, Series 24V | Voltage - Primary | 115V |
| Voltage - Isolation | 1500Vrms | Type | Laminated Core |
| Termination Style | Solder, Quick Connect | Size / Dimension | 71.42mm L x 52.37mm W |
| Series | - | Secondary Winding(s) | Dual |
| Primary Winding(s) | Single | Power - Max | 24 VA |
| Mounting Type | Chassis Mount | Manufacturer Standard Lead Time | 16 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Height - Seated (Max) | 60.33mm |
| Current - Output (Max) | Parallel 500mA, Series 250mA | Center Tap | Yes |
This browser does not support inline PDFs. Please download the PDF to view it: Download PDF
