TPD3215M
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy TPD3215M with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy TPD3215M with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | TPD3215M |
|---|---|
| Manufacturer | Transphorm |
| Description | CASCODE GAN HB 600V 70A MODULE |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | ||
|---|---|---|---|---|---|
| $75.479 | $71.836 | $69.233 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | TPD3215M | Manufacturer | Transphorm |
|---|---|---|---|
| Description | CASCODE GAN HB 600V 70A MODULE | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 432 pcs | Data sheet | TPD3215M |
| Category | Discrete Semiconductor Products | Vgs(th) (Max) @ Id | - |
| Supplier Device Package | Module | Series | - |
| Rds On (Max) @ Id, Vgs | 34 mOhm @ 30A, 8V | Power - Max | 470W |
| Packaging | Bulk | Package / Case | Module |
| Other Names | TPH3215M TPH3215M-ND |
Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Input Capacitance (Ciss) (Max) @ Vds | 2260pF @ 100V |
| Gate Charge (Qg) (Max) @ Vgs | 28nC @ 8V | FET Type | 2 N-Channel (Half Bridge) |
| FET Feature | GaNFET (Gallium Nitride) | Drain to Source Voltage (Vdss) | 600V |
| Detailed Description | Mosfet Array 2 N-Channel (Half Bridge) 600V 70A (Tc) 470W Through Hole Module | Current - Continuous Drain (Id) @ 25°C | 70A (Tc) |
This browser does not support inline PDFs. Please download the PDF to view it: Download PDF
