TMC1420-LA
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy TMC1420-LA with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy TMC1420-LA with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | TMC1420-LA |
|---|---|
| Manufacturer | TRINAMIC Motion Control GmbH |
| Description | MOSFET N/P-CH 40V 8PQFN |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | TMC1420-LA | Manufacturer | TRINAMIC Motion Control GmbH |
|---|---|---|---|
| Description | MOSFET N/P-CH 40V 8PQFN | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 4061 pcs | Data sheet | TMC1420-LA |
| Category | Discrete Semiconductor Products | Vgs(th) (Max) @ Id | 3V @ 250µA |
| Supplier Device Package | PQFN (5x6) | Series | - |
| Rds On (Max) @ Id, Vgs | 26.5 mOhm @ 7A, 10V | Power - Max | 3.57W |
| Packaging | Tape & Reel (TR) | Package / Case | 8-PowerTDFN |
| Other Names | 03-0003 03-0003X 1460-1139-2 |
Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Input Capacitance (Ciss) (Max) @ Vds | 1050pF @ 15V |
| Gate Charge (Qg) (Max) @ Vgs | 11.2nC @ 4.5V | FET Type | N and P-Channel |
| FET Feature | Standard | Drain to Source Voltage (Vdss) | 40V |
| Detailed Description | Mosfet Array N and P-Channel 40V 8.8A, 7.3A 3.57W Surface Mount PQFN (5x6) | Current - Continuous Drain (Id) @ 25°C | 8.8A, 7.3A |
