TSM-104-01-T-DV-A


OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy TSM-104-01-T-DV-A with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy TSM-104-01-T-DV-A with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
Part Number | TSM-104-01-T-DV-A |
---|---|
Manufacturer | Samtec, Inc. |
Description | CONN HEADER 8POS .100" DBL SMD |
Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
Reference Price (In US Dollars) | 1 pcs | ||||
---|---|---|---|---|---|
$0.431 |
- Product parameter
- Data sheet
Product parameter
Part Number | TSM-104-01-T-DV-A | Manufacturer | Samtec, Inc. |
---|---|---|---|
Description | CONN HEADER 8POS .100" DBL SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
Quantity Available | 69534 pcs | Data sheet | TSM Double Row, Vertical FootprintTSM-1 Series DrawingTSM Series Datasheet |
Category | Connectors, Interconnects | Voltage Rating | - |
Termination | Solder | Style | Board to Board or Cable |
Shrouding | Unshrouded | Series | TSM |
Row Spacing - Mating | 0.100" (2.54mm) | Pitch - Mating | 0.100" (2.54mm) |
Packaging | Tube | Overall Contact Length | - |
Operating Temperature | -55°C ~ 105°C | Number of Rows | 2 |
Number of Positions Loaded | All | Number of Positions | 8 |
Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
Material Flammability Rating | UL94 V-0 | Mated Stacking Heights | - |
Manufacturer Standard Lead Time | 3 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
Insulation Material | Liquid Crystal Polymer (LCP) | Insulation Height | 0.100" (2.54mm) |
Insulation Color | Black | Ingress Protection | - |
Features | Board Guide | Fastening Type | Push-Pull |
Detailed Description | Connector Header Surface Mount 8 position 0.100" (2.54mm) | Current Rating | - |
Contact Type | Male Pin | Contact Shape | Square |
Contact Material | Phosphor Bronze | Contact Length - Post | - |
Contact Length - Mating | 0.230" (5.84mm) | Contact Finish Thickness - Post | - |
Contact Finish Thickness - Mating | - | Contact Finish - Post | Tin |
Contact Finish - Mating | Tin | Connector Type | Header |
Applications | - |
