STGWA15S120DF3
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy STGWA15S120DF3 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy STGWA15S120DF3 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | STGWA15S120DF3 |
|---|---|
| Manufacturer | STMicroelectronics |
| Description | IGBT 1200V 15A TO247-3L |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 30 pcs | 120 pcs | 510 pcs | 1020 pcs |
|---|---|---|---|---|---|
| $2.594 | $2.233 | $1.939 | $1.689 | $1.471 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | STGWA15S120DF3 | Manufacturer | STMicroelectronics |
|---|---|---|---|
| Description | IGBT 1200V 15A TO247-3L | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 26778 pcs | Data sheet | STGW(A)15S120DF3 |
| Category | Discrete Semiconductor Products | Voltage - Collector Emitter Breakdown (Max) | 1200V |
| Vce(on) (Max) @ Vge, Ic | 2.05V @ 15V, 15A | Test Condition | 600V, 15A, 22 Ohm, 15V |
| Td (on/off) @ 25°C | 23ns/140ns | Switching Energy | 540µJ (on), 1.38mJ (off) |
| Supplier Device Package | TO-247-3 | Series | - |
| Reverse Recovery Time (trr) | 270ns | Power - Max | 259W |
| Packaging | Tube | Package / Case | TO-247-3 |
| Other Names | 497-15626-5 | Operating Temperature | -55°C ~ 175°C (TJ) |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Input Type | Standard |
| IGBT Type | Trench Field Stop | Gate Charge | 53nC |
| Detailed Description | IGBT Trench Field Stop 1200V 30A 259W Through Hole TO-247-3 | Current - Collector Pulsed (Icm) | 60A |
| Current - Collector (Ic) (Max) | 30A |
