Home > Products > Discrete Semiconductor Products > Transistors - IGBTs - Single > STGP20M65DF2

STGP20M65DF2

STGP20M65DF2
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy STGP20M65DF2 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number STGP20M65DF2
Manufacturer STMicroelectronics
Description IGBT TRENCH 650V 40A TO220
Lead Free Status / RoHS Status Lead free / RoHS Compliant
In Stock 87283 pcs
Reference Price
(In US Dollars)		1 pcs10 pcs100 pcs500 pcs1000 pcs
$0.832$0.747$0.60$0.493$0.409

Submit a Request For Quotation on quantities greater than those displayed.

Target Price:(USD)
Quantity:
Total:
$0.832

Product parameter

Part Number STGP20M65DF2 Manufacturer STMicroelectronics
Description IGBT TRENCH 650V 40A TO220 Lead Free Status / RoHS Status Lead free / RoHS Compliant
Quantity Available 87283 pcs Data sheet STGP20M65DF2Power Mgmt Guide Brochure
Category Discrete Semiconductor Products Voltage - Collector Emitter Breakdown (Max) 650V
Vce(on) (Max) @ Vge, Ic 2V @ 15V, 20A Test Condition 400V, 20A, 12 Ohm, 15V
Td (on/off) @ 25°C 26ns/108ns Switching Energy 140µJ (on), 560µJ (off)
Supplier Device Package TO-220 Series M
Reverse Recovery Time (trr) 166ns Power - Max 166W
Package / Case TO-220-3 Other Names 497-17909
STGP20M65DF2-ND
Operating Temperature -55°C ~ 175°C (TJ) Mounting Type Through Hole
Moisture Sensitivity Level (MSL) 1 (Unlimited) Manufacturer Standard Lead Time 42 Weeks
Lead Free Status / RoHS Status Lead free / RoHS Compliant Input Type Standard
IGBT Type Trench Field Stop Gate Charge 63nC
Detailed Description IGBT Trench Field Stop 650V 40A 166W Through Hole TO-220 Current - Collector Pulsed (Icm) 80A
Current - Collector (Ic) (Max) 40A

This browser does not support inline PDFs. Please download the PDF to view it: Download PDF
