ST2-DC9V-F
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy ST2-DC9V-F with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy ST2-DC9V-F with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | ST2-DC9V-F |
|---|---|
| Manufacturer | Panasonic |
| Description | RELAY GENERAL PURPOSE DPST 8A 9V |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 50 pcs | ||||
|---|---|---|---|---|---|
| $3.43 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | ST2-DC9V-F | Manufacturer | Panasonic |
|---|---|---|---|
| Description | RELAY GENERAL PURPOSE DPST 8A 9V | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 9312 pcs | Data sheet | ST Series Datasheet |
| Category | Relays | Turn On Voltage (Max) | 7.2 VDC |
| Turn Off Voltage (Min) | 0.9 VDC | Termination Style | PC Pin |
| Switching Voltage | 380VAC, 250VDC - Max | Series | ST |
| Release Time | 10ms | Relay Type | General Purpose |
| Packaging | Tube | Other Names | 255-3614 ST2-DC9V-F-ND ST2DC9VF |
| Operating Temperature | -40°C ~ 60°C | Operate Time | 15ms |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 14 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Features | Sealed - Fully | Detailed Description | General Purpose Relay DPST-NO (2 Form A) 9VDC Coil Through Hole |
| Contact Rating (Current) | 8A | Contact Material | Silver Tin Oxide (AgSnO) |
| Contact Form | DPST-NO (2 Form A) | Coil Voltage | 9VDC |
| Coil Type | Non Latching | Coil Resistance | 360 Ohms |
| Coil Power | 240 mW | Coil Current | 25.0mA |
