S20F1C-P05MFG0-500S
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy S20F1C-P05MFG0-500S with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy S20F1C-P05MFG0-500S with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | S20F1C-P05MFG0-500S |
|---|---|
| Manufacturer | ODU |
| Description | CONN PLUG MALE 5POS GOLD SOLDER |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $15.426 | $13.927 | $13.343 | $12.509 | $12.092 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | S20F1C-P05MFG0-500S | Manufacturer | ODU |
|---|---|---|---|
| Description | CONN PLUG MALE 5POS GOLD SOLDER | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 2671 pcs | Data sheet | ODU MINI-SNAP® Series F CatalogODU MINI-SNAP F Assembly Instruction |
| Category | Connectors, Interconnects | Voltage Rating | - |
| Termination | Solder Cup | Shielding | Shielded |
| Shell Size, MIL | - | Shell Size - Insert | 0 |
| Shell Material | Brass | Shell Finish | Chrome over Nickel |
| Series | ODU MINI-SNAP® F | Packaging | Bulk |
| Other Names | 1907-1521 | Orientation | 1 |
| Operating Temperature | -40°C ~ 120°C | Number of Positions | 5 |
| Mounting Type | Free Hanging (In-Line) | Mounting Feature | - |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-0 |
| Manufacturer Standard Lead Time | 7 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insert Material | Polyetheretherketone (PEEK) | Ingress Protection | IP50 - Dust Protected |
| Features | Backshell, Strain Relief | Fastening Type | Push-Pull |
| Detailed Description | 5 Position Circular Connector Plug, Male Pins Solder Cup Gold | Current Rating | - |
| Contact Material | Brass | Contact Finish Thickness - Mating | - |
| Contact Finish - Mating | Gold | Connector Type | Plug, Male Pins |
| Color | Silver | Cable Opening | 0.177" ~ 0.197" (4.50mm ~ 5.00mm) |
| Backshell Material, Plating | Brass, Chrome over Nickel | Applications | Industrial, Medical, Military, Testing Equipment & Measurement |
This browser does not support inline PDFs. Please download the PDF to view it: Download PDF
