Home > Products > Capacitors > Aluminum Electrolytic Capacitors > UPM1C682MHD

UPM1C682MHD

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy UPM1C682MHD with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	UPM1C682MHD
Manufacturer	Nichicon
Description	CAP ALUM 6800UF 20% 16V RADIAL
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	1000 pcs	2500 pcs	5000 pcs
~~In Stock~~ 64553 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	100 pcs	500 pcs
	$0.868	$0.702	$0.536	$0.408
	$0.357	$0.344	$0.332

Product parameter
Data sheet

Product parameter

Part Number	UPM1C682MHD	Manufacturer	Nichicon
Description	CAP ALUM 6800UF 20% 16V RADIAL	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	64553 pcs	Data sheet	Miniature Type Taping Spec UPM Series Datasheet
Category	Capacitors	Voltage - Rated	16V
Tolerance	±20%	Surface Mount Land Size	-
Size / Dimension	0.709" Dia (18.00mm)	Series	UPM
Ripple Current @ Low Frequency	2.74A @ 120Hz	Ripple Current @ High Frequency	3.05A @ 10kHz
Ratings	-	Polarization	Polar
Packaging	Bulk	Package / Case	Radial, Can
Other Names	493-5603 UPM1C682MHD-ND	Operating Temperature	-55°C ~ 105°C
Mounting Type	Through Hole	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Manufacturer Standard Lead Time	29 Weeks	Lifetime @ Temp.	5000 Hrs @ 105°C
Lead Spacing	0.295" (7.50mm)	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Impedance	18 mOhms	Height - Seated (Max)	1.476" (37.50mm)
ESR (Equivalent Series Resistance)	-	Detailed Description	6800µF 16V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C
Capacitance	6800µF	Applications	General Purpose
