30101AC
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 30101AC with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 30101AC with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 30101AC |
|---|---|
| Manufacturer | Murata Power Solutions |
| Description | FIXED IND 97NH 36A 0.35 MOHM SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1000 pcs | ||||
|---|---|---|---|---|---|
| $0.219 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | 30101AC | Manufacturer | Murata Power Solutions |
|---|---|---|---|
| Description | FIXED IND 97NH 36A 0.35 MOHM SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 107935 pcs | Data sheet | 3000A Series |
| Category | Inductors, Coils, Chokes | Type | Wirewound |
| Tolerance | ±20% | Supplier Device Package | - |
| Size / Dimension | 0.276" L x 0.276" W (7.00mm x 7.00mm) | Shielding | Shielded |
| Series | 3000A | Ratings | - |
| Q @ Freq | - | Packaging | Tape & Reel (TR) |
| Package / Case | 2-SMD | Other Names | 811-2816-2 |
| Operating Temperature | -40°C ~ 130°C | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material - Core | - |
| Manufacturer Standard Lead Time | 16 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance Frequency - Test | 1MHz | Inductance | 97nH |
| Height - Seated (Max) | 0.195" (4.96mm) | Frequency - Self Resonant | - |
| Detailed Description | 97nH Shielded Wirewound Inductor 36A 0.35 mOhm Max 2-SMD | DC Resistance (DCR) | 0.35 mOhm Max |
| Current Rating | 36A | Current - Saturation | 41A |
This browser does not support inline PDFs. Please download the PDF to view it: Download PDF
