349-10-159-00-560000
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 349-10-159-00-560000 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 349-10-159-00-560000 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 349-10-159-00-560000 |
|---|---|
| Manufacturer | Mill-Max |
| Description | CONN HEADER 59POS SMD SNGL ROW |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 100 pcs | 500 pcs | |
|---|---|---|---|---|---|
| $3.671 | $3.41 | $2.973 | $2.711 | ||
| 1000 pcs | 5000 pcs | 10000 pcs | |||
| $2.492 | $2.273 | $2.186 | |||
- Product parameter
Product parameter
| Part Number | 349-10-159-00-560000 | Manufacturer | Mill-Max |
|---|---|---|---|
| Description | CONN HEADER 59POS SMD SNGL ROW | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 13666 pcs | Data sheet | |
| Category | Connectors, Interconnects | Voltage Rating | - |
| Termination | Solder | Style | Board to Board |
| Shrouding | Unshrouded | Series | 349 |
| Row Spacing - Mating | - | Pitch - Mating | 0.100" (2.54mm) |
| Packaging | Bulk | Overall Contact Length | - |
| Other Names | ED3259 ED3259-ND ED3264-59 |
Operating Temperature | - |
| Number of Rows | 1 | Number of Positions Loaded | All |
| Number of Positions | 59 | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | - |
| Mated Stacking Heights | - | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insulation Material | Polycyclohexylenedimethylene Terephthalate (PCT) | Insulation Height | 0.110" (2.79mm) |
| Insulation Color | Black | Ingress Protection | - |
| Features | - | Fastening Type | Push-Pull |
| Detailed Description | Connector Header Surface Mount 59 position 0.100" (2.54mm) | Current Rating | - |
| Contact Type | Male Pin | Contact Shape | Circular |
| Contact Material | - | Contact Length - Post | - |
| Contact Length - Mating | 0.136" (3.45mm) | Contact Finish Thickness - Post | 10.0µin (0.25µm) |
| Contact Finish Thickness - Mating | 10.0µin (0.25µm) | Contact Finish - Post | Gold |
| Contact Finish - Mating | Gold | Connector Type | Header |
| Applications | - |
