Home > Products > Integrated Circuits (ICs) > PMIC - Display Drivers > ICM7211IPL+

ICM7211IPL+

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy ICM7211IPL+ with confidence from Components-World.HK, 1 Year Warranty

Dowload ICM7211IPL+ Details in PDF

Request a Quote

Part Number	ICM7211IPL+
Manufacturer	Maxim Integrated
Description	IC DECODR/DVR LCD 4DIGIT 40-DIP
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	50 pcs	250 pcs	500 pcs
~~In Stock~~ 22660 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	25 pcs
	$2.241	$2.129	$1.755
	$1.668	$1.615	$1.459

Product parameter
Data sheet

Product parameter

Part Number	ICM7211IPL+	Manufacturer	Maxim Integrated
Description	IC DECODR/DVR LCD 4DIGIT 40-DIP	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	22660 pcs	Data sheet	ICM7211-12
Category	Integrated Circuits (ICs)	Voltage - Supply	3 V ~ 6 V
Supplier Device Package	40-PDIP	Series	-
Packaging	Tube	Package / Case	40-DIP (0.600", 15.24mm)
Operating Temperature	-20°C ~ 85°C	Mounting Type	Through Hole
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Interface	BCD	Display Type	LCD
Digits or Characters	4 Digits	Current - Supply	10µA
Configuration	7 Segment	Base Part Number	ICM7211

This browser does not support inline PDFs. Please download the PDF to view it: Download PDF
