Home > Products > Discrete Semiconductor Products > Diodes - Rectifiers - Single > SCS220AMC

SCS220AMC

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SCS220AMC with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	SCS220AMC
Manufacturer	LAPIS Semiconductor
Description	DIODE SCHOTTKY 650V 20A TO220FM
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	250 pcs	500 pcs	1000 pcs
~~In Stock~~ 18917 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	25 pcs	100 pcs
	$3.271	$2.944	$2.682	$2.42
	$2.224	$2.028	$1.766

Product parameter
Data sheet

Product parameter

Part Number	SCS220AMC	Manufacturer	LAPIS Semiconductor
Description	DIODE SCHOTTKY 650V 20A TO220FM	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	18917 pcs	Data sheet	SCS220AM SiC Power Devices Catalog TO-220FM Taping Spec Schottky Barrier Diode Part No. Explanation
Category	Discrete Semiconductor Products	Voltage - Forward (Vf) (Max) @ If	1.55V @ 20A
Voltage - DC Reverse (Vr) (Max)	650V	Supplier Device Package	TO-220FM
Speed	No Recovery Time > 500mA (Io)	Series	-
Reverse Recovery Time (trr)	0ns	Packaging	Tube
Package / Case	TO-220-2 Full Pack	Operating Temperature - Junction	175°C (Max)
Mounting Type	Through Hole	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Manufacturer Standard Lead Time	26 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Diode Type	Silicon Carbide Schottky	Detailed Description	Diode Silicon Carbide Schottky 650V 20A Through Hole TO-220FM
Current - Reverse Leakage @ Vr	400µA @ 600V	Current - Average Rectified (Io)	20A
Capacitance @ Vr, F	730pF @ 1V, 1MHz	Base Part Number	SCS220
