2SA854STPR
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 2SA854STPR with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 2SA854STPR with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 2SA854STPR |
|---|---|
| Manufacturer | LAPIS Semiconductor |
| Description | TRANS PNP 32V 0.5A SPT |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | 2SA854STPR | Manufacturer | LAPIS Semiconductor |
|---|---|---|---|
| Description | TRANS PNP 32V 0.5A SPT | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 4145 pcs | Data sheet | 2SA854S |
| Category | Discrete Semiconductor Products | Voltage - Collector Emitter Breakdown (Max) | 32V |
| Vce Saturation (Max) @ Ib, Ic | 600mV @ 50mA, 500mA | Transistor Type | PNP |
| Supplier Device Package | SPT | Series | - |
| Power - Max | 300mW | Packaging | Tape & Box (TB) |
| Package / Case | SC-72 Formed Leads | Operating Temperature | 150°C (TJ) |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Frequency - Transition | 200MHz |
| Detailed Description | Bipolar (BJT) Transistor PNP 32V 500mA 200MHz 300mW Through Hole SPT | DC Current Gain (hFE) (Min) @ Ic, Vce | 180 @ 100mA, 3V |
| Current - Collector Cutoff (Max) | 1µA (ICBO) | Current - Collector (Ic) (Max) | 500mA |
This browser does not support inline PDFs. Please download the PDF to view it: Download PDF
