H11A3X
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy H11A3X with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy H11A3X with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | H11A3X |
|---|---|
| Manufacturer | Isocom Components |
| Description | OPTOISO 5.3KV TRANS W/BASE 6DIP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 100 pcs | 250 pcs |
|---|---|---|---|---|---|
| $0.204 | $0.16 | $0.133 | $0.115 | $0.102 | |
| 500 pcs | 1040 pcs | 3120 pcs | 5200 pcs | ||
| $0.088 | $0.068 | $0.061 | $0.057 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | H11A3X | Manufacturer | Isocom Components |
|---|---|---|---|
| Description | OPTOISO 5.3KV TRANS W/BASE 6DIP | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 371330 pcs | Data sheet | H11A1(X) - H11A5(X) |
| Category | Isolators | Voltage - Output (Max) | 30V |
| Voltage - Isolation | 5300Vrms | Voltage - Forward (Vf) (Typ) | 1.2V |
| Vce Saturation (Max) | 400mV | Turn On / Turn Off Time (Typ) | - |
| Supplier Device Package | 6-DIP | Series | - |
| Rise / Fall Time (Typ) | 2µs, 2µs | Packaging | Tube |
| Package / Case | 6-DIP (0.300", 7.62mm) | Output Type | Transistor with Base |
| Other Names | H11A3IS H11A3IS-ND |
Operating Temperature | -55°C ~ 100°C |
| Number of Channels | 1 | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 2 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Input Type | DC |
| Detailed Description | Optoisolator Transistor with Base Output 5300Vrms 1 Channel 6-DIP | Current Transfer Ratio (Min) | 20% @ 10mA |
| Current Transfer Ratio (Max) | - | Current - Output / Channel | 50mA |
| Current - DC Forward (If) (Max) | 60mA |
