IRLBL1304
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy IRLBL1304 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy IRLBL1304 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | IRLBL1304 |
|---|---|
| Manufacturer | International Rectifier (Infineon Technologies) |
| Description | MOSFET N-CH 40V 185A SUPER D2PAK |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | IRLBL1304 | Manufacturer | International Rectifier (Infineon Technologies) |
|---|---|---|---|
| Description | MOSFET N-CH 40V 185A SUPER D2PAK | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Quantity Available | 5606 pcs | Data sheet | IRLBL1304 |
| Category | Discrete Semiconductor Products | Vgs(th) (Max) @ Id | 1V @ 250µA |
| Vgs (Max) | ±16V | Technology | MOSFET (Metal Oxide) |
| Supplier Device Package | SUPER D2-PAK | Series | HEXFET® |
| Rds On (Max) @ Id, Vgs | 4.5 mOhm @ 110A, 10V | Power Dissipation (Max) | 300W (Tc) |
| Packaging | Tube | Package / Case | Super D2-Pak |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | Input Capacitance (Ciss) (Max) @ Vds | 7660pF @ 25V |
| Gate Charge (Qg) (Max) @ Vgs | 140nC @ 4.5V | FET Type | N-Channel |
| FET Feature | - | Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V |
| Drain to Source Voltage (Vdss) | 40V | Detailed Description | N-Channel 40V 185A (Tc) 300W (Tc) Surface Mount SUPER D2-PAK |
| Current - Continuous Drain (Id) @ 25°C | 185A (Tc) |
