1650E
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 1650E with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 1650E with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 1650E |
|---|---|
| Manufacturer | Hammond Manufacturing |
| Description | AUDIOPHILE TUBE OUTPUT TRANSFRMR |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $40.341 | $38.996 | $36.307 | $33.618 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 1650E | Manufacturer | Hammond Manufacturing |
|---|---|---|---|
| Description | AUDIOPHILE TUBE OUTPUT TRANSFRMR | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 956 pcs | Data sheet | 1650E Drawing1608 - 1650 A Series |
| Category | Transformers | Weight | 3.5 lbs (1.6kg) |
| Voltage - Isolation | 2000V @ 1 Second | Turns Ratio - Primary:Secondary | - |
| Transformer Type | Push-Pull Audiophile, Ultra-Linear - Tube Output | Termination Style | Wire Leads |
| Size / Dimension | 3.250" L x 2.500" W (82.55mm x 63.50mm) | Series | A |
| Return Loss | - | Power Level | 15W |
| Packaging | Bulk | Other Names | 1650E-ND HM4347 |
| Operating Temperature | - | Mounting Type | Chassis Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 4 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insertion Loss | - |
| Impedance - Secondary (Ohms) | 4, 8, 16 | Impedance - Primary (Ohms) | 8kCT |
| Height - Seated (Max) | 3.060" (77.72mm) | Frequency Response | ±1dB |
| Frequency Range | 30Hz ~ 30kHz | DC Resistance (DCR) - Secondary | 154 mOhm, 218 mOhm, 303 mOhm |
| DC Resistance (DCR) - Primary | 98.98 Ohm, 101.9 Ohm | Approvals | - |
This browser does not support inline PDFs. Please download the PDF to view it: Download PDF
