143D
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 143D with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 143D with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 143D |
|---|---|
| Manufacturer | Hammond Manufacturing |
| Description | TRANSFORMER AUDIO 200K/1K IMPED |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | ||||
|---|---|---|---|---|---|
| $11.604 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | 143D | Manufacturer | Hammond Manufacturing |
|---|---|---|---|
| Description | TRANSFORMER AUDIO 200K/1K IMPED | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 2606 pcs | Data sheet | 140-146 Series |
| Category | Transformers | Weight | 0.031 lb (14.06g) |
| Voltage - Isolation | - | Turns Ratio - Primary:Secondary | - |
| Transformer Type | Economical Open Type | Termination Style | Wire Leads |
| Size / Dimension | 1.000" L x 0.690" W (25.40mm x 17.53mm) | Series | 143 |
| Return Loss | - | Power Level | 25mW |
| Packaging | Bulk | Operating Temperature | - |
| Mounting Type | Chassis Mount | Manufacturer Standard Lead Time | 4 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insertion Loss | - |
| Impedance - Secondary (Ohms) | 1k | Impedance - Primary (Ohms) | 200k |
| Height - Seated (Max) | 0.690" (17.53mm) | Frequency Response | ±1dB |
| Frequency Range | 150Hz ~ 15kHz | DC Resistance (DCR) - Secondary | 30 Ohm |
| DC Resistance (DCR) - Primary | 4.5 kOhm | Approvals | - |
This browser does not support inline PDFs. Please download the PDF to view it: Download PDF
