124D
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 124D with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 124D with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 124D |
|---|---|
| Manufacturer | Hammond Manufacturing |
| Description | TRANSFRMR AUDIO 7KCT/15.8KCT IMP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $14.146 | $13.673 | $12.73 | $11.787 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 124D | Manufacturer | Hammond Manufacturing |
|---|---|---|---|
| Description | TRANSFRMR AUDIO 7KCT/15.8KCT IMP | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 3270 pcs | Data sheet | 124 Series Spec.124D DataSheet |
| Category | Transformers | Weight | - |
| Voltage - Isolation | 500Vrms | Turns Ratio - Primary:Secondary | 1:1.49 |
| Transformer Type | Tube Driver and Speaker Matching | Termination Style | Wire Leads |
| Size / Dimension | 2.810" L x 1.460" W (71.37mm x 37.08mm) | Series | 124 |
| Return Loss | - | Power Level | 5W |
| Packaging | Bulk | Other Names | 124D-ND HM2511 |
| Operating Temperature | - | Mounting Type | Chassis Mount |
| Moisture Sensitivity Level (MSL) | Not Applicable | Manufacturer Standard Lead Time | 4 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insertion Loss | - |
| Impedance - Secondary (Ohms) | 15.8kCT | Impedance - Primary (Ohms) | 7kCT |
| Height - Seated (Max) | 1.680" (42.67mm) | Frequency Response | ±1dB |
| Frequency Range | 150Hz ~ 15kHz | DC Resistance (DCR) - Secondary | 297 Ohm, 394 Ohm |
| DC Resistance (DCR) - Primary | 218 Ohm, 236 Ohm | Approvals | - |
This browser does not support inline PDFs. Please download the PDF to view it: Download PDF
