09185647904
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 09185647904 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 09185647904 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
Part Number | 09185647904 |
---|---|
Manufacturer | HARTING |
Description | CONN HEADER 64POS T/H |
Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
---|---|---|---|---|---|
$1.711 | $1.641 | $1.504 | $1.436 | ||
100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
$1.367 | $1.196 | $1.162 | $0.991 |
- Product parameter
- Data sheet
Product parameter
Part Number | 09185647904 | Manufacturer | HARTING |
---|---|---|---|
Description | CONN HEADER 64POS T/H | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
Quantity Available | 31533 pcs | Data sheet | SEK Male Header w/str pins |
Category | Connectors, Interconnects | Voltage Rating | - |
Termination | Solder | Style | Board to Cable/Wire |
Shrouding | Shrouded - 4 Wall | Series | SEK |
Row Spacing - Mating | 0.100" (2.54mm) | Pitch - Mating | 0.100" (2.54mm) |
Packaging | Bulk | Overall Contact Length | 0.650" (16.51mm) |
Other Names | 09185647904-ND 1195-4583 |
Operating Temperature | -55°C ~ 125°C |
Number of Rows | 2 | Number of Positions Loaded | All |
Number of Positions | 64 | Mounting Type | Through Hole |
Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-0 |
Mated Stacking Heights | - | Manufacturer Standard Lead Time | 3 Weeks |
Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insulation Material | Polybutylene Terephthalate (PBT), Glass Filled |
Insulation Height | 0.681" (17.30mm) | Insulation Color | Gray |
Ingress Protection | - | Features | Keying Slot, Mounting Flange |
Fastening Type | Latch Lock/Eject Hooks, Long | Detailed Description | Connector Header Through Hole 64 position 0.100" (2.54mm) |
Current Rating | - | Contact Type | Male Pin |
Contact Shape | Square | Contact Material | Copper Alloy |
Contact Length - Post | 0.114" (2.90mm) | Contact Length - Mating | 0.228" (5.80mm) |
Contact Finish Thickness - Post | - | Contact Finish Thickness - Mating | - |
Contact Finish - Post | Tin | Contact Finish - Mating | - |
Connector Type | Header | Applications | - |
