B65981A0000R092
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy B65981A0000R092 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy B65981A0000R092 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | B65981A0000R092 |
|---|---|
| Manufacturer | EPCOS |
| Description | FERRITE CORE PQ 4.7UH N92 2PCS |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 144 pcs | ||||
|---|---|---|---|---|---|
| $2.61 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | B65981A0000R092 | Manufacturer | EPCOS |
|---|---|---|---|
| Description | FERRITE CORE PQ 4.7UH N92 2PCS | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 12652 pcs | Data sheet | B65981A,82E Datasheet |
| Category | Magnetics - Transformer, Inductor Components | Width | 32.00mm |
| Tolerance | -20%, +30% | Supplier Device Package | PQ 50 x 50 |
| Series | B65981A | Other Names | B65981A R 92 B65981AR92 B65981AR92-ND |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Minimum Core Cross Section (Amin) mm² | 290 |
| Material | N92 | Manufacturer Standard Lead Time | 24 Weeks |
| Length | 50.00mm | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance Factor (Al) | 4.7µH | Height | 25.00mm |
| Gap | Ungapped | Finish | Uncoated |
| Effective Permeability (µe) | 1170 | Effective Magnetic Volume (Ve) mm³ | 37270 |
| Effective Length (le) mm | 113 | Effective Area (Ae) mm² | 330 |
| Diameter | - | Core Type | PQ |
| Core Factor (ΣI/A) mm1 | 0.342 |
This browser does not support inline PDFs. Please download the PDF to view it: Download PDF
