Home > Products > Magnetics - Transformer, Inductor Components > Ferrite Cores > B65671T0630A048

B65671T0630A048

B65671T0630A048

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy B65671T0630A048 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	B65671T0630A048
Manufacturer	EPCOS
Description	FERRITE CORE P 630NH N48 2PCS
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	100 pcs	250 pcs	500 pcs	1000 pcs
~~In Stock~~ 35490 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	25 pcs	50 pcs
	$2.146	$1.83	$1.392	$1.352
	$1.193	$1.114	$1.034	$0.994

Product parameter
Data sheet

Product parameter

Part Number	B65671T0630A048	Manufacturer	EPCOS
Description	FERRITE CORE P 630NH N48 2PCS	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	35490 pcs	Data sheet	B65671/2/5/9 Datasheet
Category	Magnetics - Transformer, Inductor Components	Width	-
Tolerance	±3%	Supplier Device Package	P 26 x 16
Series	B65671	Other Names	495-5164 B65671T 630A 48 B65671T630A48 B65671T630A48-ND
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Minimum Core Cross Section (Amin) mm²	76.5
Material	N48	Manufacturer Standard Lead Time	24 Weeks
Length	-	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Inductance Factor (Al)	630nH	Height	8.15mm
Gap	Gapped	Finish	Uncoated
Effective Permeability (µe)	201	Effective Magnetic Volume (Ve) mm³	3460
Effective Length (le) mm	37.2	Effective Area (Ae) mm²	93
Diameter	26.00mm	Core Type	P (Pot Core)
Core Factor (ΣI/A) mm1	0.4
