EN3P3F16X
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy EN3P3F16X with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy EN3P3F16X with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | EN3P3F16X |
|---|---|
| Manufacturer | Conxall / Switchcraft |
| Description | CONN RCPT FMALE 3POS SOLDER CUP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $3.103 | $2.967 | $2.697 | $2.562 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $2.495 | $2.225 | $2.09 | $1.848 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | EN3P3F16X | Manufacturer | Conxall / Switchcraft |
|---|---|---|---|
| Description | CONN RCPT FMALE 3POS SOLDER CUP | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 19102 pcs | Data sheet | EN3 Series BulletinEN3PxFxx DrawingEN3 Series Part Numbering |
| Category | Connectors, Interconnects | Voltage Rating | 250VAC/DC |
| Termination | Solder Cup | Shielding | Unshielded |
| Shell Size, MIL | - | Shell Size - Insert | - |
| Shell Material | Thermoplastic | Shell Finish | - |
| Series | EN3® | Packaging | Bulk |
| Other Names | EN3P3F16 EN3P3F16-ND EN3P3F16X-ND SC2502 |
Orientation | Keyed |
| Operating Temperature | -40°C ~ 65°C | Number of Positions | 3 |
| Mounting Type | Panel Mount | Mounting Feature | Bulkhead - Front Side Nut |
| Moisture Sensitivity Level (MSL) | Not Applicable | Material Flammability Rating | UL94 V-0 |
| Manufacturer Standard Lead Time | 12 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insert Material | Elastomer | Ingress Protection | IP66/68 - Dust Tight, Water Resistant, Waterproof |
| Features | - | Fastening Type | Bayonet Lock |
| Detailed Description | 3 Position Circular Connector Receptacle, Female Sockets Solder Cup Gold | Current Rating | 13A |
| Contact Material | Copper Alloy | Contact Finish Thickness - Mating | - |
| Contact Finish - Mating | Gold | Connector Type | Receptacle, Female Sockets |
| Color | Black | Cable Opening | - |
| Backshell Material, Plating | - | Applications | General Purpose, Instrumentation, Marine, Medical |
This browser does not support inline PDFs. Please download the PDF to view it: Download PDF
