EN3P2M16X
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy EN3P2M16X with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy EN3P2M16X with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | EN3P2M16X |
|---|---|
| Manufacturer | Conxall / Switchcraft |
| Description | CONN RCPT MALE 2POS SOLDER CUP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $1.746 | $1.41 | $1.293 | $1.234 | ||
| 100 pcs | 250 pcs | 500 pcs | |||
| $1.175 | $1.028 | $1.02 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | EN3P2M16X | Manufacturer | Conxall / Switchcraft |
|---|---|---|---|
| Description | CONN RCPT MALE 2POS SOLDER CUP | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 30749 pcs | Data sheet | EN3 Series BulletinEN3PxMxx DrawingEN3 Series Part Numbering |
| Category | Connectors, Interconnects | Voltage Rating | 250VAC/DC |
| Termination | Solder Cup | Shielding | Unshielded |
| Shell Size, MIL | - | Shell Size - Insert | - |
| Shell Material | Thermoplastic | Shell Finish | - |
| Series | EN3® | Packaging | Bulk |
| Other Names | EN3P2M16 EN3P2M16-ND EN3P2M16X-ND SC1572 |
Orientation | Keyed |
| Operating Temperature | -40°C ~ 65°C | Number of Positions | 2 |
| Mounting Type | Panel Mount | Mounting Feature | Bulkhead - Front Side Nut |
| Material Flammability Rating | UL94 V-0 | Manufacturer Standard Lead Time | 12 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insert Material | Elastomer |
| Ingress Protection | IP66/68 - Dust Tight, Water Resistant, Waterproof | Features | - |
| Fastening Type | Bayonet Lock | Detailed Description | 2 Position Circular Connector Receptacle, Male Pins Solder Cup Gold |
| Current Rating | 13A | Contact Material | Copper Alloy |
| Contact Finish Thickness - Mating | - | Contact Finish - Mating | Gold |
| Connector Type | Receptacle, Male Pins | Color | Black |
| Cable Opening | - | Backshell Material, Plating | - |
| Applications | General Purpose, Instrumentation, Marine, Medical |
