D4F
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy D4F with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy D4F with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
Part Number | D4F |
---|---|
Manufacturer | Conxall / Switchcraft |
Description | CONN PLUG FMALE XLR 4POS SOLDER |
Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | ||
---|---|---|---|---|---|
$4.08 | $3.739 | $3.626 | |||
50 pcs | 100 pcs | 250 pcs | |||
$3.456 | $3.399 | $3.332 |
- Product parameter
- Data sheet
Product parameter
Part Number | D4F | Manufacturer | Conxall / Switchcraft |
---|---|---|---|
Description | CONN PLUG FMALE XLR 4POS SOLDER | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
Quantity Available | 10648 pcs | Data sheet | D_F Series Drawing |
Category | Connectors, Interconnects | Voltage Rating | 125VAC |
Termination | Solder Cup | Shielding | - |
Shell Size, MIL | - | Shell Size - Insert | XLR |
Shell Material | Stainless Steel | Shell Finish | - |
Series | Q-G® D | Packaging | Bulk |
Other Names | SC1019 | Orientation | Keyed |
Operating Temperature | - | Number of Positions | 4 |
Mounting Type | Panel Mount | Mounting Feature | Flange |
Material Flammability Rating | - | Manufacturer Standard Lead Time | 12 Weeks |
Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insert Material | Polyester |
Ingress Protection | - | Features | Ground |
Fastening Type | Latch Lock | Detailed Description | 4 Position Circular Connector Plug, Female Sockets Solder Cup Silver |
Current Rating | 10A | Contact Material | Phosphor Bronze |
Contact Finish Thickness - Mating | - | Contact Finish - Mating | Silver |
Connector Type | Plug, Female Sockets | Color | Silver |
Cable Opening | - | Backshell Material, Plating | - |
Applications | Audio, Instrumentation |
