3505FX
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 3505FX with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 3505FX with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 3505FX |
|---|---|
| Manufacturer | Conxall / Switchcraft |
| Description | CONN RCA JACK MONO 3.2MM PNL MT |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $1.319 | $1.065 | $0.976 | $0.932 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $0.888 | $0.777 | $0.754 | $0.721 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 3505FX | Manufacturer | Conxall / Switchcraft |
|---|---|---|---|
| Description | CONN RCA JACK MONO 3.2MM PNL MT | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 51401 pcs | Data sheet | Phono Plugs |
| Category | Connectors, Interconnects | Voltage - Rated | - |
| Thread Size | 3/8"-32 | Termination | Solder Eyelet(s) |
| Signal Lines | Mono | Shielding | Unshielded |
| Series | - | Panel Hole Size | 0.375" (9.52mm) |
| Packaging | Bulk | Other Names | 3505F 3505F-ND 3505FX-ND Q2362958A SC1984 |
| Operating Temperature | - | Number of Positions/Contacts | 2 Conductors, 2 Contacts |
| Mounting Type | Panel Mount | Mating Length/Depth | - |
| Manufacturer Standard Lead Time | 12 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Internal Switch(s) | Does Not Contain Switch | Insulation Color | White |
| Industry Recognized Mating Diameter | 3.20mm ID, 9.00mm OD (RCA) | Includes | 3 pcs - 1 Connector, 1 Nut, 1 Washer |
| Housing Material | - | Gender | Female |
| Features | Grounding Tab, Mounting Hardware | Detailed Description | 3.20mm ID, 9.00mm OD (RCA) Phono (RCA) Jack Mono Connector Solder Eyelet(s) |
| Contact Material - Plating | Nickel | Contact Material | Copper Alloy |
| Connector Type | Phono (RCA) Jack | Cable Opening | - |
| Body Material | Copper Alloy | Body Color | Silver |
| Actual Diameter | - |
