3009W4SCM99A10X
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 3009W4SCM99A10X with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 3009W4SCM99A10X with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 3009W4SCM99A10X |
|---|---|
| Manufacturer | Conec |
| Description | CONN DSUB RCPT 9POS STR SLDR CUP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $2.803 | $2.688 | $2.454 | $2.337 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $2.22 | $1.987 | $1.87 | $1.636 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 3009W4SCM99A10X | Manufacturer | Conec |
|---|---|---|---|
| Description | CONN DSUB RCPT 9POS STR SLDR CUP | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 21920 pcs | Data sheet | 3009W4SCM99A10X Drawing |
| Category | Connectors, Interconnects | Wire Gauge | 20 AWG |
| Voltage Rating | - | Termination | Solder Cup |
| Shell Size, Connector Layout | 3 (DB, B) - 9W4 | Shell Material, Finish | Steel, Tin Plated |
| Series | - | Packaging | Tray |
| Other Names | 626-1117 | Operating Temperature | -55°C ~ 125°C |
| Number of Rows | 2 | Number of Positions | 9 (5 + 4 Coax or Power) |
| Mounting Type | Free Hanging (In-Line) | Material Flammability Rating | UL94 V-0 |
| Manufacturer Standard Lead Time | 12 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Ingress Protection | IP20 | Housing Material | Polybutylene Terephthalate (PBT), Glass Filled |
| Flange Feature | Housing/Shell (Unthreaded) | Features | - |
| Detailed Description | 9 (5 + 4 Coax or Power) Position D-Sub, Combo Receptacle, Female Sockets Connector | Current Rating | - |
| Contact Type | Signal and Coax or Power (Not Included) | Contact Material | Copper Alloy |
| Contact Form | - | Contact Finish Thickness | 30.0µin (0.76µm) |
| Contact Finish | Gold | Connector Type | Receptacle, Female Sockets |
| Connector Style | D-Sub, Combo | Color | Green |
| Backset Spacing | - |
