164A17009X
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 164A17009X with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 164A17009X with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 164A17009X |
|---|---|
| Manufacturer | Conec |
| Description | CONN D-SUB HD RCPT 15POS STR |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $3.368 | $3.223 | $2.93 | $2.783 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $2.71 | $2.417 | $2.271 | $2.007 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 164A17009X | Manufacturer | Conec |
|---|---|---|---|
| Description | CONN D-SUB HD RCPT 15POS STR | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 14818 pcs | Data sheet | 164A170x9X Drawing |
| Category | Connectors, Interconnects | Wire Gauge | 22 AWG |
| Voltage Rating | 60V | Termination | Solder Cup |
| Shell Size, Connector Layout | 1 (DE, E) High Density | Shell Material, Finish | Steel, Tin Plated |
| Series | 164A | Packaging | Bulk |
| Other Names | 626-1601 | Operating Temperature | -55°C ~ 125°C |
| Number of Rows | 3 | Number of Positions | 15 |
| Mounting Type | Free Hanging (In-Line) | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Material Flammability Rating | UL94 V-0 | Manufacturer Standard Lead Time | 12 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Ingress Protection | IP20 |
| Housing Material | Polybutylene Terephthalate (PBT), Glass Filled | Flange Feature | Housing/Shell (Unthreaded) |
| Features | - | Detailed Description | 15 Position D-Sub, High Density Receptacle, Female Sockets Connector |
| Current Rating | 3A | Contact Type | Signal |
| Contact Material | Copper Alloy | Contact Form | Machined |
| Contact Finish Thickness | Flash | Contact Finish | Gold |
| Connector Type | Receptacle, Female Sockets | Connector Style | D-Sub, High Density |
| Color | Black | Backset Spacing | - |
