MDM-21SSB
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy MDM-21SSB with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy MDM-21SSB with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | MDM-21SSB |
|---|---|
| Manufacturer | Cannon |
| Description | CONN MICRO-D RCPT 21POS PNL MNT |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 100 pcs | ||
|---|---|---|---|---|---|
| $40.77 | $38.371 | $32.855 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | MDM-21SSB | Manufacturer | Cannon |
|---|---|---|---|
| Description | CONN MICRO-D RCPT 21POS PNL MNT | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Quantity Available | 1019 pcs | Data sheet | 096515-0009Microminiature CatalogMDM-21SSB Datasheet |
| Category | Connectors, Interconnects | Wire Gauge | - |
| Voltage Rating | - | Termination | Solder Cup |
| Shell Size, Connector Layout | 0.050 Pitch x 0.043 Row to Row | Shell Material, Finish | Aluminum, Yellow Chromate Cadmium Plated |
| Series | 83513-Style Micro D Metal Shell (MDM) | Packaging | Bulk |
| Other Names | 096515-0009 1003-1286 965150009 |
Operating Temperature | -55°C ~ 125°C |
| Number of Rows | 2 | Number of Positions | 21 |
| Mounting Type | Panel Mount | Moisture Sensitivity Level (MSL) | Not Applicable |
| Material Flammability Rating | - | Manufacturer Standard Lead Time | 15 Weeks |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | Ingress Protection | - |
| Housing Material | Liquid Crystal Polymer (LCP) | Flange Feature | Housing/Shell (Unthreaded) |
| Features | Shielded | Detailed Description | 21 Position D-Type, Micro-D Receptacle, Female Sockets Connector |
| Current Rating | 3A | Contact Type | Signal |
| Contact Material | Copper Alloy | Contact Form | - |
| Contact Finish Thickness | - | Contact Finish | Gold |
| Connector Type | Receptacle, Female Sockets | Connector Style | D-Type, Micro-D |
| Color | - | Backset Spacing | - |
This browser does not support inline PDFs. Please download the PDF to view it: Download PDF
