7814J-1-023E
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 7814J-1-023E with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 7814J-1-023E with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 7814J-1-023E |
|---|---|
| Manufacturer | Bourns, Inc. |
| Description | SWITCH ROTARY DIP SPDT 100MA 16V |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 500 pcs | 1000 pcs | 5000 pcs | ||
|---|---|---|---|---|---|
| $0.43 | $0.383 | $0.335 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | 7814J-1-023E | Manufacturer | Bourns, Inc. |
|---|---|---|---|
| Description | SWITCH ROTARY DIP SPDT 100MA 16V | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 58015 pcs | Data sheet | 7814 Rotary Switch |
| Category | Switches | Washable | No |
| Voltage Rating | 16VAC/DC | Termination Style | J Lead |
| Series | 7814 | Pitch | - |
| Packaging | Tape & Reel (TR) | Other Names | 7814J-001-023E 7814J-023ETR 7814J1023E |
| Operating Temperature | -55°C ~ 125°C | Number of Positions | 2 |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Mechanical Life | 2,000 Cycles | Manufacturer Standard Lead Time | 14 Weeks |
| Length | 0.177" (4.50mm) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Height Above Board | 0.100" (2.54mm) | Features | - |
| Electrical Life | - | Detailed Description | Dip Switch SPDT 2 Position Surface Mount Rotary for Tool Actuator 100mA 16VAC/DC |
| Current Rating | 100mA | Contact Material | - |
| Contact Finish | - | Circuit | SPDT |
| Body Material | - | Actuator Type | Rotary for Tool |
| Actuator Level | Flush, Recessed |
This browser does not support inline PDFs. Please download the PDF to view it: Download PDF
