ST-7-10
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy ST-7-10 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy ST-7-10 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | ST-7-10 |
|---|---|
| Manufacturer | Bel |
| Description | XFRMR LAMINATED 36VA THRU HOLE |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $5.782 | $4.405 | $4.061 | $3.924 | ||
| 100 pcs | 250 pcs | 500 pcs | |||
| $3.855 | $3.717 | $3.662 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | ST-7-10 | Manufacturer | Bel |
|---|---|---|---|
| Description | XFRMR LAMINATED 36VA THRU HOLE | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 10169 pcs | Data sheet | Split/Tran™ Low Power Transformers |
| Category | Transformers | Weight | 1.1 lbs (499g) |
| Voltage - Secondary (Full Load) | Parallel 5V, Series 10V | Voltage - Primary | 115V |
| Voltage - Isolation | 2500Vrms | Type | Laminated Core |
| Termination Style | PC Pin | Size / Dimension | 66.70mm L x 55.50mm W |
| Series | ST | Secondary Winding(s) | Dual |
| Primary Winding(s) | Single | Power - Max | 36 VA |
| Other Names | 595-1992 ST-7-10-ND |
Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | Not Applicable | Manufacturer Standard Lead Time | 16 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Height - Seated (Max) | 40.40mm |
| Current - Output (Max) | Parallel 7.2A, Series 3.6A | Center Tap | No |
This browser does not support inline PDFs. Please download the PDF to view it: Download PDF
