SA56EX
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SA56EX with confidence from Components-World.HK, 1 Year Warranty
Dowload SA56EX Details in PDFSee Product Specifications for product details.
Buy SA56EX with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | SA56EX |
|---|---|
| Manufacturer | Apex Microtechnology |
| Description | IC MOTOR DRIVER PAR 23SIP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | SA56EX | Manufacturer | Apex Microtechnology |
|---|---|---|---|
| Description | IC MOTOR DRIVER PAR 23SIP | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 5054 pcs | Data sheet | SA56EX EK22 |
| Category | Integrated Circuits (ICs) | Voltage - Supply | 4.5 V ~ 5.5 V |
| Voltage - Load | 12 V ~ 60 V | Technology | DMOS |
| Supplier Device Package | 23-SIP | Series | Apex Precision Power® |
| Rds On (Typ) | 270 mOhm LS, 230 mOhm HS | Packaging | Tube |
| Package / Case | 23-SIP Formed Leads | Output Configuration | Half Bridge (2) |
| Other Names | 598-1361 | Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Load Type | Inductive | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Interface | PWM | Features | Status Flag |
| Fault Protection | Over Temperature | Detailed Description | Half Bridge (2) Driver DC Motors, General Purpose DMOS 23-SIP |
| Current - Peak Output | 10A | Current - Output / Channel | 5A |
| Base Part Number | SA* | Applications | DC Motors, General Purpose |
