PT07A-14-5P


OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy PT07A-14-5P with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy PT07A-14-5P with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
Part Number | PT07A-14-5P |
---|---|
Manufacturer | Amphenol Industrial |
Description | CONN RCPT MALE 5POS SOLDER CUP |
Lead Free Status / RoHS Status | Lead free / RoHS non-compliant |
Reference Price (In US Dollars) | 1 pcs | 5 pcs | 10 pcs | 25 pcs | |
---|---|---|---|---|---|
$10.671 | $9.331 | $9.091 | $8.565 | ||
50 pcs | 100 pcs | 250 pcs | 500 pcs | ||
$7.991 | $7.082 | $6.699 | $6.555 |
- Product parameter
- Data sheet
Product parameter
Part Number | PT07A-14-5P | Manufacturer | Amphenol Industrial |
---|---|---|---|
Description | CONN RCPT MALE 5POS SOLDER CUP | Lead Free Status / RoHS Status | Lead free / RoHS non-compliant |
Quantity Available | 5741 pcs | Data sheet | PT07A DrawingPT Series Catalog |
Category | Connectors, Interconnects | Voltage Rating | - |
Termination | Solder Cup | Shielding | Unshielded |
Shell Size, MIL | - | Shell Size - Insert | 14-5 |
Shell Material | Aluminum | Shell Finish | Olive Drab Chromate over Cadmium |
Series | MIL-DTL-26482 Series I, PT | Packaging | Bulk |
Other Names | PT07A145P U71-146714-05P |
Orientation | N (Normal) |
Operating Temperature | -55°C ~ 125°C | Number of Positions | 5 |
Mounting Type | Panel Mount | Mounting Feature | Bulkhead - Front Side Nut |
Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | - |
Manufacturer Standard Lead Time | 12 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS non-compliant |
Insert Material | Neoprene | Ingress Protection | - |
Features | - | Fastening Type | Bayonet Lock |
Detailed Description | 5 Position Circular Connector Receptacle, Male Pins Solder Cup Gold | Current Rating | - |
Contact Material | Copper Alloy | Contact Finish Thickness - Mating | - |
Contact Finish - Mating | Gold | Connector Type | Receptacle, Male Pins |
Color | Olive Drab | Cable Opening | - |
Backshell Material, Plating | - | Applications | Aerospace, Industrial, Instrumentation, Mass Transit, Military |
This browser does not support inline PDFs. Please download the PDF to view it: Download PDF
