132147-48
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 132147-48 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 132147-48 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 132147-48 |
|---|---|
| Manufacturer | Amphenol Connex (Amphenol RF) |
| Description | CONN SMA RCPT STR 50 OHM SOLDER |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $4.042 | $3.673 | $3.582 | $3.306 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $3.122 | $2.847 | $2.663 | $2.443 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 132147-48 | Manufacturer | Amphenol Connex (Amphenol RF) |
|---|---|---|---|
| Description | CONN SMA RCPT STR 50 OHM SOLDER | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 14341 pcs | Data sheet | 132147-48 Drawing |
| Category | Connectors, Interconnects | Voltage Rating | 500V |
| Shield Termination | Solder | Series | - |
| Packaging | Bulk | Other Names | 132147-48-ND 13214748 ARF2754 |
| Operating Temperature | -65°C ~ 165°C | Number of Ports | 1 |
| Mounting Type | Panel Mount | Mounting Feature | Flange |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Mating Cycles | 500 |
| Manufacturer Standard Lead Time | 9 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insertion Loss | - | Ingress Protection | - |
| Includes | - | Impedance | 50 Ohm |
| Housing Color | Gold | Frequency - Max | 12.4GHz |
| Features | Extended Insulation | Fastening Type | Threaded |
| Dielectric Material | Polytetrafluoroethylene (PTFE) | Detailed Description | SMA Connector Receptacle, Female Socket 50 Ohm Panel Mount Solder |
| Contact Termination | Solder | Connector Type | Receptacle, Female Socket |
| Connector Style | SMA | Center Contact Plating | Gold |
| Center Contact Material | Beryllium Copper | Cable Group | - |
| Body Material | Brass | Body Finish | Gold |
This browser does not support inline PDFs. Please download the PDF to view it: Download PDF
